| Tempat asal: | Cina |
| Nama merek: | 100% Neutral |
| Sertifikasi: | CE, FCC, RoHs, TUV |
| Nomor model: | HW-AP2200 |
| Kuantitas min Order: | 100PCS |
|---|---|
| Harga: | $170/PCS~$183/PCS |
| Kemasan rincian: | Ukuran Produk: 183mm * 183mm * 43mm |
| Waktu pengiriman: | 7 hari kerja |
| Syarat-syarat pembayaran: | T/T,, L/C |
| Menyediakan kemampuan: | 10000pcs per bulan |
| Chipset: | Qualcomm IPQ4019 + QCA9886 + QCA8075 | ||
|---|---|---|---|
| Cahaya Tinggi: | access point base station,outdoor wifi access point |
||
Fitur utama:
Spesifikasi Produk:
| Perangkat keras: | |||||
| Chipset | Qualcomm IPQ4019 + QCA9886 + QCA8075 | ||||
| Standar | 802.11ac / b / g / n, teknologi MU-MIMO | ||||
| Ingatan | RAM DDR3 512MB | ||||
| Flash | 32MB | ||||
| Antarmuka | Port WAN RJ45 1 * 10/100 / 1000Mbps | ||||
| Port LAN RJ45 1 * 10/100 / 1000Mbps (Di dalam cangkang) | |||||
| 1 * Tombol Reset, tekan 10 detik untuk kembali ke pengaturan default | |||||
| Antena | 6 * konektor tipe-N, bekerja dengan antena 6dBi Omni 6PCS. | ||||
| Konsumsi daya | 48V PoE <30W | ||||
| Ukuran | 183mm * 183mm * 43mm | ||||
| Tingkat Bukti Air | IP65 | ||||
| Data RF | |||||
| 2.4G: 802.11b / g / n: 2.4GHz - 2.484GHz | ||||
| 5GHz: 802.11a / n / ac MIMO: 5.150GHz ～ 5.850GHz | |||||
| Modulasi | OFDM = BPSK, QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM | ||||
| DSSS = DBPSK, DQPSK, CCK | |||||
| Throughput | 2200Mbps | ||||
| 2.4G Daya RF (IPQ4019) | 802.11b | 11 jt | 23 ± 2dBm | 1 jt | 25 ± 2dBm |
| 802.11g | 54 jt | 22 ± 2dBm | 6 jt | 24 ± 2dBm | |
| 802.11n HT20 | MCS7 | 21 ± 2dBm | MCS0 | 23 ± 2dBm | |
| 802.11n HT40 | MCS7 | 21 ± 2dBm | MCS0 | 23 ± 2dBm | |
Daya RF 5G | 802.11a | 54 jt | 19 ± 2dBm | 6 jt | 21 ± 2dBm |
| 802.11n HT20 | MCS7 | 18 ± 2dBm | MCS0 | 20 ± 2dBm | |
| 802.11n HT40 | MCS7 | 18 ± 2dBm | MCS0 | 20 ± 2dBm | |
| 802.11ac HT80 | MCS9 | 17 ± 2dBm | MCS0 | 19 ± 2dBm | |
Daya RF 5G | 802.11a | 54 jt | 19 ± 2dBm | 6 jt | 21 ± 2dBm |
| 802.11n HT20 | MCS7 | 18 ± 2dBm | MCS0 | 20 ± 2dBm | |
| 802.11n HT40 | MCS7 | 18 ± 2dBm | MCS0 | 20 ± 2dBm | |
| 802.11ac HT80 | MCS9 | 17 ± 2dBm | MCS0 | 19 ± 2dBm | |
| 2.4G Menerima Sensitivitas | 802.11b | 11 jt | -85dBm | 1 jt | -94dBm |
| 802.11g | 54 jt | -72dBm | 6 jt | -90dBm | |
| 802.11n HT20 | MCS7 | -70dBm | MCS0 | -88dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm | |
| 5G Menerima Sensitivitas | 802.11a | 54 jt | -72dBm | 6 jt | -90dBm |
| 802.11n HT20 | MCS7 | -70dBm | MCS0 | -88dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm | |
| 802.11ac HT80 | MCS9 | -58dBm | MCS0 | -85dBm | |
| EVM | 2.4G EVM: 802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28dB | ||||
| PPM | ± 20ppm | ||||
| Pengguna Maks | 256 | ||||
| Fitur Firmware: | |||||
| Mode operasi | Wireless AP, Gateway, WISP, Wi-Fi Repeater | ||||
| Jenis WAN | IP dinamis / IP Statis / PPPoE / L2TP (Akses Ganda) / PPTP (Akses Ganda) | ||||
| Keamanan Nirkabel | Enkripsi WPA / WPA2 (PSK / AES) 64/128-bit | ||||
| SSID | Beberapa SSID (4 SSID untuk 2.4G, 8 SSID untuk 5.8G) | ||||
| Firewall | Filter Alamat IP / Filter Alamat MAC / Filter Domain Binding Alamat IP dan MAC | ||||
| Protokol | IPv4 | ||||
| Lainnya: | |||||
| Isi Paket | 2200Mbps Jalur akses nirkabel Dual Band | ||||
| Persyaratan sistem | Microsoft Windows 98SE, NT, 2000, XP, Vista ™ atau Windows 7, Windows 8, MAC OS, NetWare, UNIX atau Linux | ||||
| Lingkungan Hidup | Suhu Operasional: -20 ~ 55 ℃ | ||||
| Pengelolaan | GUI Firmware, Manajemen Jarak Jauh, Pengendali WLAN, Sistem Manajemen Cloud | ||||
Tambahan:
